SS Filter Housing

SS Filter Housing
SS Filter Housing
Product Code : 22
Brand Name : SS. FILTERS
Price And Quantity
  • Minimum Order Quantity
  • 10
  • Unit of Measure
  • Set/Sets
Product Specifications
  • Usage
  • Pharmaceuticals,Sugar Industry,Dairy Industry,Bevarages,Inks & Cosmetics,Distilleries,Paints,Oil
  • Product Type
  • Filter Housing
  • Material
  • Stainless Steel
  • Type
  • Housing
  • Cartridge Style
  • Double Open End
  • Diameter
  • 8 -24 Inch (in)
  • Efficiency
  • 600 - 12000 Lt/ hr
  • Application
  • Various Purpose
Product Description
Our horizontal sparkler filters consists SS shell and top cover with swing bolts to provide pressure tight enclosure. Inside the shell, the filter cartridge assembly consists various horizontally arranged disc type filter plates with filter media, perforated supporting screens & interlocking cups.

The whole assembly complete with piping & pump connection can be mounted on an appropriate SS trolley, if needed. The components of sparkler filter are argon arc welded and mirror polished. Also, it can be jacketed for hot filtration.

Based on standard tests, a concise idea of flow rates of clean water for various sizes and sparkler filter plates are as follows:

Product Specifications:

Sr.No

Sizes of plates in dia

No of plates

Filtration area M2/ plate

Cake holding capacity- Lt

Flow rate
Lt/ hr

1

8" dia

6 plates

0.0283

0.708

600

2

8" dia

8 plates

0.042

0.85

700

3

14" dia

8 plates

0.084

2.5

1600

4

14" dia

10 plates

0.101

2.6

2000

5

18" dia

8 plates

0.142

2.75

3500

6

18" dia

12 plates

0.152

3.73

4000

7

18" dia

15 plates

0.165

3.95

6000

8

24" dia

16 plates

0.189

4.9

8000

9

24" dia

24 plates

0.195

5.5

12000



Filtration counts on quality of filter pads, viscosity of liquids and nature of liquids sediments to be filtered.

Operation:

The fluid to be filtered is pumped to the vessel of sparkler, where it gets into the individual plates. It passes through the media (cloth/paper) and crystal clear filtrate comes out by a central channel defined by interlocking cups. The cake settled between the plates can be separated if needed.

Applications:
  • Pharmaceuticals
  • Sugar industry
  • Dairy industry
  • Bevarages
  • Oil
  • Inks & Cosmetics
  • Paints
  • Distilleries
