Glass Fiber Filter

Glass Fiber Filter
Glass Fiber Filter
Product Code : GFF - 02542
Brand Name : SS. FILTERS PVT. LTD
Product Specifications
  • Outlet Diameter
  • Approx 65-67 Millimeter (mm)
  • Usage
  • Plating Solutions,Solvent Filtration,Oil And Gas Production,Photographic Film Solutions
  • Inlet Diameter
  • Approx 28 Millimeter (mm)
  • Product Type
  • Glass Fiber Filter
  • Material
  • Glass Fiber
  • Type
  • Membrane Filter Cartridge
  • Cartridge Style
  • Double Open End
  • Length
  • 250 to 1000 Millimeter (mm)
  • Efficiency
  • 7.5 sq. feet (0.6 msq.)
  • Application
  • Process Water, Wines & Flavoured Drinks, Bioprocessing Of Food Products, Distilled Spirits & Bottled Water Processes, Inks & Coatings
Product Description

Glass Fiber Filter

The Glass Fiber Filters we offer are 100% synthetic glass fibers with or without binder that gives superior strength in various liquid applications. The support layers of these products are standardized polyester or polypropylene that suit to the temperature and compatibility necessities. Our filters help to cut down the filtration costs and immature clogging when filtering becomes difficult-to-filter and an extremely contaminated solution becomes the obstruction. The filtration media united with full flow rates and high dirt-holding capabilities is the perfect choice as a prefilter in some industries. Glass Fiber Filters come with increased shelf life and give more reliable performance than other high-priced membrane filters.

Key Features & Advantages:

  • Advanced surface area filter media.
  • Prodigious high flow rates with debased pressure drops.
  • Advanced permeability to air.
  • Can be functioned at elevated temperatures.
  • Superior wet strength for simple handling and filter integrity.


Applications:

  • Process Water
  • Wines & Flavored drinks
  • Inks & Coatings
  • Distilled spirits & bottled water processes
  • Bio processing of food products
  • Plating solutions
  • Solvent filtration
  • Photographic film solutions
  • Oil and gas production



Product Specifications:

Micron Rating

1, 2 Microns

Length

250 mm to 1000 mm

Inner Dia

Approx 28mm

Outer Dia

Approx 65-67 mm

Effective surface area per 10" element

7.5 sq. feet (0.6 msq.)

Max operating temperature

80˚C continuous

Sterilization Autoclave

121˚C, 30 min, 10 times

Sterilization Hot water

80˚C, 30 min, 30 times

Max differential pressure

5.5 bar (80 psi)@ 21˚C

Material Of Construction:

Filter media

100% Microglass fiber

Support media

Polypropylene

Cartridge MOC

Polypropylene

'O' Ring/ Gaskets

Silicone/ EPDM

Configuration:

  • Double open end - DOE
  • Code 7S (226- double 'O' Ring / fin)
